Equipment

Leica Z16 APO

Product Description:

The Leica Z16 APO is a fully apochromatic zoom system for high contrast, high-resolution, detailed analysis. The single beam path provides 2D images and ensures parallax-free imaging. Together with the Leica DFC cameras and the Leica Applications Suite, this is ideal for digital imaging.

Short Specifications:

• Z16 (Z6): zoom 16:1 ( 6.3:1 ), zoom range 0.57× – 9.2× ( 0.57× – 3.6×)

• Fully apochromatic zoom system and apochromatic objectives for superlative contrast, color fidelity and detail richness

• Magnification: 7.1× – 115× ( Z16 APO), 7.1× – 45× (Z6 APO) visual with planapochromatic 1× objective, 10× eyepieces, 1.25× Y tube

• Total visual magnification with planapochromatic 5× objective, 40× eyepieces, 1.25× Y tube: 900× (Z6 APO), 2300× ( Z16 APO)

• Highest resolution: 351 Lp/mm (Z6 APO) or 336 Lp/mm (Z16 APO) visual* up to 1500 Lp/mm**

• Highest numerical aperture from: 0.117* (Z6 APO) or 0.112* ( Z16 APO) up to 0.5**

• Large working distance of 97 mm*

1. MTS 810 – Servohydraulic Material Testing System

The MTS 810 system is a completely integrated testing package to let you easily obtain information about the mechanical properties of your materials or components. With the wide range of load unit, test control, and test accessory options, it is easily configured to meet your exact testing needs.

Specifications:

Loading Capacity-100KN (22 kips)

Clamping Pressure- 3000psi

Range of Frequency- 0-100 Hz

Fixtures:

ASTM Test Fixtures: Tension D3039; 1. Compression D6641; 2. V-notch rail shear D7078; 3. Flexure D790/6272/7264; Short Beam D2344; 4. Boeing Compression after Impact D7137; 5. Boeing Open Hole Compression D6484; 6. Climbing Drum Peel Test D1781.

Flat Grips:

0-7.6mm; 7.1-14.2mm; and 11.7-19.1mm

Round Grips:

12mm (broken); 15mm; and 20mm

Extensometer:

0.5” gage length; Strain Range: +/- 9%

1” gage length; Strain Range: 0 to 100 %

INSTRON CEAST 9340-LOW VELOCITY IMPACT TESTER

The CEAST 9340 is a floor-standing impact system. It is suitable for various impact applications including tensile impact, penetration tests on plates and films, Izod, and Charpy tests.

Specification:

• Max. Energy- 0.3-405J
• Max. drop height- 0.03-1.1m
• Max impact velocity- 0.77-4.85 m/s (square root of 2gh)
• Max dropping mass 37.5kg
• Compressed air requirement =5bar
• Max Energy = mgh = Max mass x 9.81 x Max height = 37.5 x 9.81 x 1.1 = 405J

TMA Q400-Thermo Mechanical Analyzer

The Q400 features a rugged and reliable furnace. Its customized electronics provide excellent heating rate control and rapid response over a wide temperature range. Located in the furnace core, the easily accessed chamber provides complete temperature and atmosphere control for sample analysis. Data precision is enhanced by mass flow control of the purge gas. It can be used for Intrinsic and product property measurements, accurate coefficient of thermal expansion (CTE) measurements, material performance and selection,  multilayer film analysis, film property testing, film tensile testing, fiber stress/strain measurements, thermal stress analysis of fibers and creep analysis.

Specifications:

• Temperature Range; -150 to 1,000 ^oC
• Maximum Sample Size (solid) : 26mm (L) x 10 mm (D)
• Maximum Sample Size (film/fiber) : 26mm (L) x 0.5 mm(T) x 4.7 mm (W)
• Measurement Precision : +/- 0.1%
• Sensitivity : 15 nm
• Force Range : 0.001 to 1 N
• Atmosphere : inert, Oxidizing, or Reactive Gases

Leica Z16 APO A Optical Microscope

The Leica Z16 APO is a fully apochromatic zoom system for high contrast, high-resolution, detailed analysis. The single beam path provides 2D images and ensures parallax-free imaging. Together with the Leica DFC cameras and the Leica Applications Suite, this is ideal for digital imaging.

Short Specifications:

• Z16 (Z6): zoom 16:1 ( 6.3:1 ), zoom range 0.57× – 9.2× ( 0.57× – 3.6×)

• Fully apochromatic zoom system and apochromatic objectives for superlative contrast, color fidelity and detail richness

• Magnification: 7.1× – 115× ( Z16 APO), 7.1× – 45× (Z6 APO) visual with planapochromatic 1× objective, 10× eyepieces, 1.25× Y tube

• Total visual magnification with planapochromatic 5× objective, 40× eyepieces, 1.25× Y tube: 900× (Z6 APO), 2300× ( Z16 APO)

• Highest resolution: 351 Lp/mm (Z6 APO) or 336 Lp/mm (Z16 APO) visual* up to 1500 Lp/mm**

• Highest numerical aperture from: 0.117* (Z6 APO) or 0.112* ( Z16 APO) up to 0.5**

• Large working distance of 97 mm*

SM-8200 Digital Super Megohmmeter

The SM-8200 Digital Super Megohmmeter series are insulation resistance meters consisting of a constant voltage power supply and a high sensitivity current measuring element, and are designed to measure the electrical resistance of insulation materials with high insulating properties. When paired with super megohmmeters, the Hioki-SM8310 can measure the surface and volume resistance of plate samples. It is particularly useful when high insulation resistance cannot be properly measured due to effects from noise and induction hum in the measuring environment.

Specification:

Measuring Resistance Range: 5V (2.5E4Ω – 10E11Ω) - 1000V (5E6Ω – 2E13Ω)

Measuring Accuracy : +/- 10%

Output Current: Max. 2 mA

Interfaces: RS-232C, Comparator output (open-collector)

Power Supply: Selectable 100, 120, 220 or 240V AC ±10%, 50/60 Hz, 25 VA

TA Discovery SDT 650 – Differential Scanning Calorimetry & Thermogravimetric Analysis

The SDT 650 allows studying the change in transitions of a polymer under conditions of controlled temperature, time, and atmosphere. It has a dual horizontal beam design for superior heat flow and weight measurements to analyze two materials simultaneously. The SDT 650 uses TRIOS software for instrument control, data analysis, and reporting. It is a high-performance, ease-of-use device that is reliable and can be used in a wide variety of applications, including glass transition temperature, heat capacity, weight Loss, crystallization transition temperature, melt transition temperature, and stress relaxation analysis among others.

Specifications:

• Temperature Range (max): Ambient to 1500ºC
• Temperature Precision: ±0.5ºC
• Heating rate (linear): 0.1 to 100ºC/min
• Calorimetric Accuracy/ Precision: +/- 2%
• Heat capacity accuracy: +/- 5%
• Sample weight accuracy: 200 mg
• Weighing accuracy: +/-0.5%
• Weighing Precision: +/-0.1%
• Vacuum:50 μTorr

LulzBot TAZ 3D printer

LulzBot TAZ 3D printer is a ready-to-print powerhouse that builds on the unmatched reliability and print quality of its predecessors while offering more material options than ever before. Itis the industry’s most reliable and easiest-to-use desktop 3D printer. The next generation of the award-winning LulzBot TAZ line includes a strengthened design, improved motion system, premium hot end, and new automatic calibration features.

Short Specifications:

3D Printing Technology : FFF (Fused Filament Fabrication)

Build Volume : 280 x 280 x 285 mm (11.02 x 11.02 x 11.22 inches)

Equipped Layer Height Range : 0.1mm (100 microns) to 0.4mm (400 microns)

Platform Layer Height Capabilities : 0.05mm (50 microns) to 1.8mm (1800 microns)

Nozzle Diameter & Material : 0.5mm Nickel Plated Copper

Maximum Hot End Temperature : 290°C (554°F) - Firmware Limited Maximum Travel Speed: 300 mm/s - Firmware Limited Print Bed Heater : 360W 24V Silicon

Maximum Print Bed Temperature : 110°C (230°F)

Operating Temperature Range : 41°F to 113°F (5°C to 45°C)

Supported Print Materials : PLA, TPU, ABS, PETg, PVA, PVB, Nylon, PC, and others below 290°C
